For users needing to process long or medium-thick plates, the 110T_3200mm High-speed Pump-controlled Servo CNC Press Brake is a practical choice. Its positioning is clear: serving mass production in industries such as chassis and cabinets, elevator sheet metal, building curtain walls, and automotive parts. If you are a medium-sized processing plant or a complete equipment manufacturer looking for a machine capable of handling your main production tasks, this machine's configuration and performance should meet your expectations.
Machine Structure
To ensure the flatness of the 3.2-meter-long worktable under load, the machine body is constructed from Q355B high-strength steel plates through integral welding. Post-weld vibration aging treatment is then performed to completely eliminate internal stress within the metal. This process ensures the machine tool possesses extremely high structural rigidity and deformation resistance, enabling it to adapt to long-term, high-frequency continuous operation and avoiding processing errors caused by deformation of the machine frame itself. The machine body surface undergoes sandblasting and electrostatic powder coating treatment, resulting in a strong coating adhesion and excellent corrosion and wear resistance. This allows it to withstand dusty or high-humidity industrial environments, ensuring a long service life.
The power system of the 110T_3200mm High-speed Pump-controlled Servo CNC Press Brake employs a closed-loop control system composed of a servo motor and a variable pump. Unlike traditional hydraulic presses that operate continuously at full load, this system outputs flow on demand, resulting in more precise power response. Actual test data shows that compared to traditional models, it reduces energy consumption by 30% to 50%, while also minimizing hydraulic oil temperature rise, reducing the frequency of seal aging and oil changes, thus lowering maintenance costs and failure rates.
Technical Specifications
| Nominal Pressure | 1100kN (110 tons) |
| Table Length | 3200mm |
| Column Spacing | 2700mm |
| Throat Depth | 350mm (Standard) |
| Slider Stroke | 200mm |
| Opening Height | 480mm |
| Slider Speed | Rapid Down 160mm/s, Feed 5-20mm/s (Adjustable), Return 120mm/s |
| Back Gauge Speed | 200mm/s, Repeat Positioning Accuracy ±0.01mm |
| Bending Accuracy | Angle Accuracy ±0.1° |
| Machining Range | Cold Rolled Steel ≤6mm, Stainless Steel ≤4mm |
| Main Motor Power | 7.5kW |
| Number of Control Axes | Standard 4 Axes (Y1/Y2/X/R) |
Precision Control and Operation
To ensure straightness when bending long plates, a 110T_3200mm High-speed Pump-controlled Servo CNC Press is used. Brake employs a dual-cylinder servo synchronous drive with a linear encoder for closed-loop detection, monitoring and correcting the slider position in real time. The worktable is equipped with a standard mechanical deflection compensation mechanism to compensate for deflection deformation caused by stress, ensuring uniform bending angles across the entire sheet metal.
The control system supports graphical programming and 3D simulation, featuring automatic calculation and angle correction for bending processes. The interface is logically clear and supports multiple languages, helping to shorten operator learning cycles and changeover/adjustment time. The back gauge is driven by a servo motor, combined with a ball screw and linear guide, ensuring precise and reliable positioning.
Safety: The equipment comes standard with a safety light curtain, emergency stop button, overload protection, and leakage protection devices, fully complying with internationally recognized industrial safety standards. These features maximize the safety of operators and the equipment itself, giving everyone peace of mind while working.
In summary, this 110T_3200mm High-speed Pump-controlled Servo CNC Press Brake machine strikes a very good balance between key performance indicators such as tonnage, table length, energy consumption, and accuracy. All parameters are based on industry-tested data, aiming to provide a stable and efficient solution for medium to large-scale sheet metal processing.
